IP68 CAST RESIN BUS DUCT

EntracoBKS is one of the poineer in Resin cast Bus Ducts. Our bus ducts have been installed worldwide from various range of inductries. From Airports to Shipping yards, Commercial complex to residencial, Industrial to software parks.

Flame retardant cast resin creates solid construction without any air gaps. This prevents the chimney effect and makes it safe. Hallogen-free material makes the bus duct toxic free.

+ Prevents chimney effect
+ Dust proof
+ Water proof
+ Fire resistant
+ Toxic free
+ Corrioson resistant
+ Chemical resistant
+ UV resistant

With EntracoBKS IP68 bus duct you get double the tap-off points, making it easier to access power.

+ Allows modification
+ Multiple tap-off
+ Low Voltage drop
+ Underground erection feasible

EntracoBKS’s proprietory design gives the flexibility needed for bus bar to expand and contract without damaging the bus duct.

+ Added at every 40 meters straight length
+ Super compact size
+ Ce 60 / Ce 90 certified

Type SB-60 H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / SB 060-03 AL 90 400 178 23 48 161.11 176.43 49.90 178.34 68 21 SC-R / SB 060-04 AL 90 630 237 23 48 120.83 141.96 41.55 151.16 68 22 SC-R / SB 060-06 AL 90 800 352 38 80 80.56 96.35 25.71 101.91 68 22

Type SB H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / SB 080 AL 110 1000 472 38 80 60.42 74.35 54.65 93.80 68 29 SC-R / SB 100 AL 130 1250 592 65 140 48.33 58.86 50.57 78.64 68 34 SC-R / SB 120 AL 150 1400 712 65 140 40.28 49.59 41.79 65.80 68 39

Type DB H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / DB 080 AL 190 1600 945 65 140 30.21 36.27 45.90 58.91 68 48 SC-R / DB 100 AL 230 2000 1185 65 140 24.17 29.48 31.38 43.32 68 58 SC-R / DB 120 AL 270 2500 1425 65 140 20.14 25.62 29.18 38.30 68 68

Type QB H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / QB 080 AL 380 3200 1889 130 280 15.10 19.03 23.93 30.69 68 95 SC-R / QB 100 AL 460 4000 2369 130 280 12.08 15.24 25.68 29.73 68 115 SC-R / QB 120 AL 540 5000 2849 130 280 10.07 12.70 23.07 26.47 68 135

Type SB-60 H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / SB 060-03 Cu 90 630 178 23 48 99 119 106 159 68 26 SC-R / SB 060-04 Cu 90 800 237 23 48 74 93 85 123 68 28 SC-R / SB 060-06 Cu 90 1000 352 38 80 49 62 69 92 68 31

Type SB H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / SB 080 Cu 110 1250 472 65 140 36.46 49.74 67.95 77.13 68 41 SC-R / SB 100 Cu 130 1600 592 65 140 29.17 35.70 58.07 68.58 68 48 SC-R / SB 120 Cu 150 1700 712 65 140 26.00 31.00 38.00 49.00 68 56

Type DB H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / DB 080 Cu 190 2000 945 65 140 18.23 22.49 28.60 36.38 68 72 SC-R / DB 100 Cu 230 2500 1185 65 140 14.58 17.62 24.51 29.89 68 87 SC-R / DB 120 Cu 270 3200 1425 65 140 12.15 15.11 17.90 23.58 68 103

Type QB H mm In A Area mm2 Ik 1 sec Ik dyn. R20 mΩ Rt mΩ X mΩ Z mΩ IP Class Wt. kg/mtr.                         SC-R / QB 080 Cu 380 4000 1889 130 280 9.11 11.30 16.66 22.24 68 142 SC-R / QB 100 Cu 460 5000 2369 130 280 7.29 8.83 17.09 20.08 68 174 SC-R / QB 120 Cu 540 6300 2849 130 280 6.08 7.58 17.81 19.37 68 205

* PER 100 METER

• Bus duct drawings not to the exact proportion.
